Leica DISTO D5-R - on FTA 360 Tripod Adapter

Leica DISTO D5-R - Automatic Rotating Display

Leica DISTO D5-R - measure outdoors-with the digital pointfinder

Leica DISTO D5-R - measure with a gesture

Leica DISTO D5-R - indirect height measurement

Leica DISTO D5 R Pro Pack

Original price was: £720.00.Current price is: £632.50. Inc. VAT: £759.00

SKU: 950879

Range: 200m | Accuracy: ± 1 mm
Bluetooth® Smart – FREE Apps Leica DISTO™ sketch & Transfer
Colour display with Digital Pointfinder 4x zoom
Rechargeable Li-ion battery
Measure by Gesture* or DIST Key* (* NEW features)
IP54: dust & splash water protected
Indirect Height Measurement | 360° Tilt Sensor
Smart Horizontal Mode | Smart Room Measurement

Supplied with:

Leica Disto D5 R Laser Measure
Leica DISTO D5 R, Pouch | Charger with Cable | Hand Loop
FTA 360 Adapter | TRI 75 Tripod | Quick Start Guide,
Warranty card | Safety Manual | Calibration Certificate Silver
3 year warranty

Description
Shipping & Delivery

Description

Outdoor laser distance measuring made easy

With the digital on screen Pointfinder the Leica DISTO D5 R makes measuring outside, even in bright sunshine and at very long distances, easy. Both the target and the measurement results can be seen very clearly on the large IPS display(iPhone quality). Avoid moving the device for accuracy when measuring using the new Gesture measure feature, move hand across laser beam and measurement is triggered…. How cool is that!

So many features to help with all manner of measuring applications, Smart Horizontal Mode, height tracking, profile or angle measurements. This means that any measurement situation on the construction site can be solved quickly and efficiently.

For vertical height measuring between 2 points mount the laser into the FTA360 Cradle Adapter and screw onto the tripod. The height tracking mode uses a digital angle tilt sensor to calculate the vertical height through rotation. The first measurement zeros the angle tilt sensor and then calculates height when you tilt the laser in the cradle upwards. Using the camera align the cross hair on the screen as a target to the desired height and a vertical measurement is calculated from the first measurement you took.

Measured data can then be Blue-toothed to the DISTO Plan app or individual templates, e.g. in Excel, email or any application to support an efficient and error-free digital workflow.

It’s important to note that the FTA360 cradle does not contain electronic encoders. Because of this, the D5R Pro Package cannot perform Point‑to‑Point (P2P) measurements left‑to‑right from a fixed position.

If you need to measure between points horizontally (left to right), you will require one of the following:

DST360 with a DISTO X3 for internal surveys
DST360‑X with a DISTO X6 for external surveys

The DST360 Cradles include the encoder technology needed to achieve true P2P measurements from a single setup position.

KEY FEATURES

Leica DISTO D5 R - FEATURES

Measure with a gesture

No need to touch the DISTO: Carefully place the laser dot or crosshairs of the Pointfinder Camera on target & simply wave a hand in front of the device to briefly interrupt the beam. When the DISTO senses this pulse, it triggers the measurement.

Multi-functional endpiece

The Multi-functional endpiece folds out from the back of the DISTO and automatically sets the measuring point to either the rear of the DISTO or the tip of the extended endpiece.

Bluetooth Keyboard Mode

In this mode, your device sees the DISTO as a Bluetooth® keyboard. Press send to deliver measured values to the cursor in any program.

Leica DISTO Plan App

Document Measurements Digitally

FIND OUT MORE >>

Leica DISTO D5 R Video Tutorials

Getting to know your DISTO D5 R

DISTO D5 R – How to measure long distances

How to use the Bluetooth keyboard mode on Leica DISTO D5 or X6 with Android & Excel

Leica DISTO: How to Measure Outdoors

How to use the digital pointfinder

Indoors or generally in favourable lighting conditions, the red laser dot is very clearly visible so that the object can be easily targeted. In bright outdoor areas, however, or even in bright sunlight, the laser dot is no longer visible. The laser distance meter can still measure without any problems. To aim, however, you now need the Pointfinder – a camera that shows you the target exactly in the crosshairs on the display.

Key Features

Indoor /outdoor laser | Digital pointfinder
Range: 200m | Accuracy: ± 1 mm
Bright and clear 2.8” IPS touchscreen with scratch-proof lens
360° tilt sensor, Measuring units: m, ft, in
Color display with Pointfinder 4x zoom
Trigger measurements with a gesture – for max accuracy
Indirect height measurement, 360° tilt sensor
DIST key on the side for even more intuitive measurements
Multi-functional, IP54 (dust- and splash water protected)
Trigger measurements with gestures
Memory for 300 reports
Li-Ion rechargeable battery
USB-C charging and download of data
Keyboard simulating data-transfer via Bluetooth®
Bluetooth® 5.0 Technology for error-free data transfer
Works with DISTO Plan App (iOS and Android) and DISTO transfer (Windows)
Compatible with DST 360-X adapter to enable P2P measurements

Specifications

Accuracy with favourable conditions *	1.0 mm / 1/16″ ***
Accuracy with unfavourable conditions **	2.0 mm / 1/8″ ***
Range with favourable conditions *	0.05 – 200 m / 0.07 – 660 ft ***
Range with unfavourable conditions **	0.05 – 120 m / 0.07 – 400 ft ***
Smallest unit displayed	0.1 mm / 1/32 in
X-Range Power Technology	yes
Laser Class 2	635 nm, <1 mW
Digital Pointfinder with 4-fold zoom	yes
Tilt measuring range ****	360°
Tilt measuring tolerance	± 0.2°
ø laser point \| at distances	6 / 30 / 60 mm \| 10 / 50 / 100 m
Protection class	IP54 (dust- and splash water protected)
Auto. laser switch off after	90 s
Auto. power switch off after	180 s
Bluetooth® Smart	Bluetooth® v5.0
Range of Bluetooth®	up to 10 m
Battery durability (Li-Ion 2 000 mAh)	up to 5’000 measurements up to 10 hours operation time
Dimension (H x D x W)	144 x 60 x 24 mm \| 5.7 x 2.4 x 0.9 in
Weight (with batteries)	180 g / 6.35 oz
Temperature range storage \| operation	-25 to 70 °C / -13 to 158 °F \| -10 to 50 °C / 14 to 122 °F

Leica DISTO D5 R Documentation

View and download this product’s brochure, datasheet, and manual in a PDF format

Leica DISTO & Leica Lino Family Brochure

Leica DISTO D5 R – Data Sheet

Leica DISTO D5 R – Quick Start Guide

Leica DISTO D5 R – User Manual
